541 Hardtail MTB Frame Deposit
Place your deposit on a 541 frame here. The total cost for a frame is $1500 and includes one set of dropout inserts, thru-axle, and your choice of powder coat color. Your deposit will be applied to the total amount due at delivery, which will be within 30 days of finalizing your order (subject to parts and powder availability).
You can learn all about the 541’s development and design features here. In the meantime, here’s the nitty-gritty.
Tubing: Size-specific Velospec front triangle, Columbus rear triangle, Custom seat tube
Dropouts: Modular UDH/Singlespeed
Intended Fork: 120-140mm suspension fork or ~500mm rigid fork
Headset SHIS: ZS44/EC44
Tire Clearance: 29 x 2.6
Brake Standard: PM160 or FM160 or ISO
Rear Hub: 148x12mm
Chainring clearance: 36t round (55mm chainline), 32t round (50mm chainline)
Bottom Bracket: T47 91.5mm
Seat Post: 31.6mm, >150mm dropper clearance on all sizes
Seat Collar: 34.9mm
Bottle Cages: 2 in main triangle, 1 under downtube (triple mount)
Cable Routing: External downtube, stealth dropper, full housing to brake/derailleur
